KEY FEATURES
Belt-drive turntable with electronically regulated speed control
Precision motor and isolated power supply for accurate, consistent rotation
Carbon fibre 9-inch tonearm designed for low tracking error
Adjustable vertical tracking angle (VTA) for precise cartridge alignment
Pre-fitted Ortofon 2M Red moving magnet cartridge
Precision milled aluminium sub-platter and hardened steel bearing assembly
Glass platter with felt mat for controlled resonance
Solid MDF plinth with tuned isolation feet
Low-resonance dust cover for added protection during playback
Detachable high-quality RCA cable with separate ground connection
GENERAL SPECIFICATIONS
Nominal speed 33/45 rpm, manual speed change (78 rpm possible with special pulley
Speed variance 33 rpm: < ± 0.35 %, 45 rpm: < ± 0.30 %
Wow and flutter <0.01% (ref. 1 kHz, Audio LPF)
Signal/Noise ratio - 70 dB
Downforce range 0 - 30 mN 0 - 3.0 grams
Supplied counterweight system 95dB
Supplied counterweight system Counterweight for cartridges: 6 - 13 g
Voltage Universal switch mode power supply 15 V DC/0,8 A, 100-240 V AC, 47 - 63Hz
Power consumption 5 W max/ 0.3W standby
TONEARM
Effective tonearm mass 9.5 g
Effective tonearm length 230 mm
Overhang 18 mm
ORTOFON 2M RED CARTRIDGE
Frequency range 20-22.000Hz
Channel separation 22dB/1kHz
Output voltage 5.5 mV
Recommended load impedance 47 kohms/Amplifier connection: MM-input
Compliance/stylus type 20μm/mN – elliptical
Recommended tracking force 18 mN
Weight 7.2g
DIMENSIONS AND WEIGHT
Gross Dimensions (W x H X D) 17 1/8 x 13 7/16 x 4 15/16” (435 x 340 x 125mm)
Shipping Weight 9.2 kg(20.3 lbs)
